Floor heating convectors
Model VCF.100.150.2PH
Height : 100 mm.
Width : 150 mm.
Natural convection
Heat output : (95/85/20 °C) 328 - 1638 W.
Heat exchanger 2 pipe, horizontal (2PH)
Standard length (mm) : 600 - 3000 mm. (100 mm. interval)
---
VCF.100.150.2PH
(Heat exchanger 2 pipe, horizontal)
The housing is made of 1 mm thick sheet steel and powder coated. Housing length L from 600 to 3000 mm., Step 100 mm. The upper part of the housing has an aluminum grille, which ensures convective heat transfer. The heat exchanger is coated with a wear-resistant powder coating.
The fittings for connecting the heat exchanger to the heating system have an internal thread G1 / 2 '' and air vent to remove air from the heating system. The distance between the connection points is 50, 150 and 250 mm. - side connection and 50 mm. - bottom connection.
---
---
---
